V support
The V-support is a support element for work positioners designed for centring and stably positioning cylindrical or shaped parts during machining operations. Available in steel or stainless steel, with a width of 300 mm and a length of 350 mm.
Work Positioner Tools · Booms
V-Support for Work Positioner Boom with Wheel
V-support to fit on the WPR-T-0002 boom with wheel: it holds reels and cylindrical loads. In painted steel or stainless steel, up to 80 kg. An accessory for the work positioner boom (reel mandrel).
Why choose it
Cylindrical loads
The V shape holds reels and rolls.
On the boom with wheel
It fits on the WPR-T-0002 boom.
From WP 55 to WP 205
50 kg on the WP 55, 80 kg from WP 85 to WP 205.
Technical data
| Specification | Value |
|---|---|
| Version | Steel, Stainless Steel |
| Length mm | 350 |
| Width mm | 300 |
The usable capacity depends on the Work Positioner the tool is fitted to: you will find it below for each model.
WP 55Usable capacity 50 kg
WP 65Usable capacity 60 kg
WP 85Usable capacity 80 kg
WP 125Usable capacity 80 kg
WP 205Usable capacity 80 kg
Boom with wheel for V supportBoom it fits onWe help you choose the right tool
Send us the weight, shape and dimensions of the load and tell us which Work Positioner you use: we will check the tool and the capacity.
